OPTIMAX 590 ep 1800 SIEMENS (V2 – 2017)
Basic composition
Chuck | manuel 3 mors Ø 250 mm* mm |
---|---|
Turret | Manuel type MULTIFIX C |
Tailstock | Manuel CM5 |
SAFETY Function | Intégrée |
Technical characteristics
Distance between centres | 1100 / 1800 mm |
---|---|
Swing over bed | 584 mm |
Machinable diameter | 300 mm |
Spindle bore diameter | 82 mm |
Rotation speed | 3000 tr/min |
Software
Control system | Commande assistée OPTIMAX V2 |
---|
OPTIMAX 360 LATHE
Designed and developed to satisfy a large range of professionals.
Through its size, its robustness and its characteristics, this lathe will fit into your workshops, as a long-term addition.
Compact and offering the operator an optimum working environment, this lathe is ideal for creating your tools, unit parts, prototypes and small-size repairs. The French machining lathe par excellence, all together modern, precise and robust, acknowledged worldwide.
Basic composition
Chuck | Manual 3 jaw Ø 215 mm |
---|---|
Turret | Manual type MULTIFIX B |
Tailstock | Manual CM4 |
Swarf conveyor | On request |
SAFETY Function | Integrated |
Technical characteristics
Distance between centres | 700 mm |
---|---|
Swing over bed | 390 mm |
Machinable diameter | 200 mm |
Spindle bore diameter | 54 mm |
Rotation speed | 4000 tr/min |
Software
Control system | OPTIMAX CNC Assistance SIEMENS numeric control |
---|
OPTIMAX 590 LATHE
Ergonomic and maximum working environment for this machine range.
For the operator, access to the machine and the space inside the cabin favours the setting up and machining of small- and medium-sized parts.
Several LED lights provide excellent visibility and precision work over the entire distance between centres.
The versatile machining lathe combines the modernity and robustness of highly-dimensioned mechanics, with a reputation worldwide.
Basic composition
Chuck | Manual 3 jaw Ø 250 mm |
---|---|
Turret | Manual type MULTIFIX C |
Tailstock | Manual CM5 |
Swarf conveyor | On request |
SAFETY Function | Integrated |
Technical characteristics
Distance between centres | 1100 / 1800 mm |
---|---|
Swing over bed | 584 mm |
Machinable diameter | 300 mm |
Spindle bore diameter | 82 mm |
Rotation speed | 3000 tr/min |
Software
Control system | OPTIMAX CNC Assistance SIEMENS numeric control |
---|
OPTIMAX 740 LATHE
Range of lathes for machining long parts (up to 4 metres).
Available in 2 or 3 axes, this lathe provides the operator with full comfort for simplified and superior quality machining, including on long parts.
The precision and the robustness of the lathe are ensured by its wide hardened and ground bed as well as by its "double V" guidance.
Basic composition
Chuck | Manual 3 jaw Ø 315 mm |
---|---|
Turret | Manual type MULTIFIX C |
Tailstock | Manual CM5 |
Swarf conveyor | On request |
SAFETY Function | Integrated |
Technical characteristics
Distance between centres | 2000 / 3000 / 4000 mm |
---|---|
Swing over bed | 740 mm |
Machinable diameter | 460 mm |
Spindle bore diameter | 105 (140) mm |
Rotation speed | Range I : 2 - 450 Range II : 200 - 2300 tr/min |
Software
Control system | OPTIMAX CNC Assistance SIEMENS numeric control |
---|
ID-MAX 500 LATHE
This lathe with an inclined bed is designed for making unit parts or runs. Removal of swarf is optimised thanks to the built-in conveyor in this compact machine. Equipped with an automatic turret, changing tools is fast and makes it possible to increase productivity as well as the machining of complex parts that require several tools. IDMAX 500 is differentiated by its prismatic guideways, guaranteeing robustness and precision over time.
Very compact despite its generous capacities, this lathe will easily find a place in your workshops.
Basic composition
Chuck | Hydraulic 3 jaw Ø 200 mm |
---|---|
Turret | Automatic 12 stations |
Tailstock | Hydraulic CM4 |
Swarf conveyor | Yes |
SAFETY Function | Integrated |
Technical characteristics
Distance between centres | 600 / 1000 mm |
---|---|
Swing over bed | 505 mm |
Machinable diameter | 350 mm |
Spindle bore diameter | 62 mm |
Rotation speed | 4500 tr/min |
Software
Control system | OPTIMAX CNC Assistance SIEMENS numeric control |
---|
ID-MAX 600 LATHE
This lathe with an inclined bed is appreciated by the industry for its robustness, its precision and its reliability, thanks in particular to its wide prismatic guideways. Both compact and versatile, this machine provides the user with great flexibility. Its machining capacities allow for the creation of small- and medium-sized parts.
More detailsBasic composition
Chuck | Hydraulic 3 jaw Ø 250 mm |
---|---|
Turret | Automatic 12 stations |
Tailstock | Hydraulic CM5 |
Swarf conveyor | Yes |
SAFETY Function | Integrated |
Technical characteristics
Distance between centres | 700 / 1200 / 1600 mm |
---|---|
Swing over bed | 610 mm |
Machinable diameter | 500 mm |
Spindle bore diameter | 86 mm |
Rotation speed | 3500 tr/min |
Software
Control system | OPTIMAX CNC Assistance SIEMENS numeric control |
---|
ID-MAX 700 LATHE
This lathe with an inclined bed provided with prismatic guideways is ideal for making unit parts or runs, of medium and large size. Its structure provides substantial volume allowing for optimum access for setting up parts, tools and accessories.
More detailsBasic composition
Chuck | Hydraulic 3 jaw Ø 300 mm |
---|---|
Turret | Automatic 12 stations |
Tailstock | Hydraulic CM5 |
Swarf conveyor | Yes |
SAFETY Function | Integrated |
Technical characteristics
Distance between centres | 1100 / 1600 / 2000 / 3000 mm |
---|---|
Swing over bed | 750 mm |
Machinable diameter | 550 mm |
Spindle bore diameter | 100 mm |
Rotation speed | 2700 tr/min |
Software
Control system | OPTIMAX CNC Assistance SIEMENS numeric control |
---|
ID-MAX 900 LATHE
This range of robust lathes with an inclined bed is designed for making heavy parts and/or large-size parts. swarf removal and precision work are ensured thanks to the characteristics of the machine, prismatic guideways and its strong motorisation.
More detailsBasic composition
Chuck | Hydraulic 3 jaw Ø 380 mm |
---|---|
Turret | Automatic 12 stations |
Tailstock | Hydraulic CM6 |
Swarf conveyor | Yes |
SAFETY Function | Integrated |
Technical characteristics
Distance between centres | 1300 / 2000 / 3000 / 4000 / 5000 mm |
---|---|
Swing over bed | 900 mm |
Machinable diameter | 700 mm |
Spindle bore diameter | 130 mm |
Rotation speed | 2000 tr/min |
Software
Control system | OPTIMAX CNC Assistance SIEMENS numeric control |
---|
